Located in the industrial heart of Manama, Bahrain, Rizwan Flanges has built a reputation for reliability as a premier manufacturer and supplier of piping components. We specialize in producing high-quality DIN 2641 PN6 Lap Joint Flanges, engineered to meet the demanding needs of various industries. Our commitment lies in delivering robust solutions that ensure seamless and secure connections in piping systems, providing our clients with the dependability and performance they need for their critical operations, backed by our local expertise and global standards.
Crafted with precision, our flanges are manufactured from carefully selected materials, ensuring a composition that guarantees strength and durability. They are designed to meet the exacting mechanical properties specified by the DIN 2641 standard for a Pressure Nominal of 6. This focus on material integrity means they offer excellent resistance to pressure and environmental stressors, providing a reliable, long-lasting performance that you can count on for even the most demanding installations.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Pipe Parameter | Flange Dimension | Screw Dimension | Flange Weight | |||||||
| DN | ISO | DIN | D | d6 | b | k | e | No. of holes | d2 | KG/PCS |
| 10 | – | 14 | 75 | 16 | 10 | 50 | 2 | 4 | 11 | 0.3 |
| 17.2 | – | 75 | 19 | 10 | 50 | 2 | 4 | 11 | 0.29 | |
| 15 | – | 20 | 80 | 22 | 10 | 55 | 2 | 4 | 11 | 0.33 |
| 21.3 | – | 80 | 24 | 10 | 55 | 2 | 4 | 11 | 0.33 | |
| 20 | – | 25 | 90 | 28 | 10 | 65 | 2 | 4 | 11 | 0.42 |
| 26.9 | – | 90 | 30 | 10 | 65 | 2 | 4 | 11 | 0.41 | |
| 25 | – | 30 | 100 | 33 | 12 | 75 | 3 | 4 | 11 | 0.62 |
| 33.7 | – | 100 | 36 | 12 | 75 | 3 | 4 | 11 | 0.61 | |
| 32 | – | 38 | 120 | 42 | 12 | 90 | 3 | 4 | 14 | 0.88 |
| 42.4 | – | 120 | 46 | 12 | 90 | 3 | 4 | 14 | 0.85 | |
| 40 | – | 44.5 | 130 | 50 | 12 | 100 | 3 | 4 | 14 | 1.01 |
| 48.3 | – | 130 | 54 | 12 | 100 | 3 | 4 | 14 | 0.98 | |
| 50 | – | 57 | 140 | 62 | 12 | 110 | 3 | 4 | 14 | 1.11 |
| 60.3 | – | 140 | 65 | 12 | 110 | 3 | 4 | 14 | 1.08 | |
| 65 | 76.1 | – | 160 | 81 | 12 | 130 | 3 | 4 | 14 | 1.35 |
| 80 | 88.9 | – | 190 | 94 | 14 | 150 | 3 | 4 | 18 | 2.24 |
| 100 | – | 108 | 210 | 113 | 14 | 170 | 3 | 4 | 18 | 2.59 |
| 114.3 | – | 210 | 119 | 14 | 170 | 3 | 4 | 18 | 2.47 | |
| 125 | – | 133 | 240 | 138 | 14 | 200 | 3 | 8 | 18 | 3.1 |
| 139.7 | – | 240 | 145 | 14 | 200 | 3 | 8 | 18 | 2.93 | |
| 150 | – | 159 | 265 | 164 | 14 | 225 | 3 | 8 | 18 | 3.52 |
| 168.3 | – | 265 | 173 | 14 | 225 | 3 | 8 | 18 | 3.25 | |
| 200 | 219.1 | – | 320 | 225 | 16 | 280 | 3 | 8 | 18 | 4.85 |
| 250 | – | 267 | 375 | 273 | 20 | 335 | 3 | 12 | 18 | 7.67 |
| 273 | – | 375 | 279 | 20 | 335 | 3 | 12 | 18 | 7.26 | |
| 300 | 323.9 | – | 440 | 329 | 24 | 395 | 4 | 12 | 22 | 11.77 |
| 350 | 355.6 | – | 490 | 362 | 26 | 445 | 4 | 12 | 22 | 16.55 |
| – | 368 | 490 | 374 | 26 | 445 | 4 | 12 | 22 | 15.13 | |
| 400 | 406.4 | – | 540 | 413 | 28 | 495 | 4 | 16 | 22 | 19.56 |
| – | 419 | 540 | 426 | 28 | 495 | 4 | 16 | 22 | 17.67 | |
| 500 | 508 | – | 645 | 517 | 32 | 600 | 4 | 20 | 22 | 27.43 |
| 600 | 610 | – | 755 | 618 | 36 | 705 | 4 | 20 | 26 | 38.75 |
| 700 | 711 | – | 860 | 721 | 40 | 810 | 4 | 24 | 26 | 50.19 |
| 800 | 813 | – | 975 | 824 | 44 | 920 | 4 | 24 | 30 | 67.83 |
| 900 | 914 | – | 1075 | 926 | 48 | 1020 | 4 | 24 | 30 | 81.84 |
| 1000 | 1016 | – | 1175 | 1028 | 52 | 1120 | 4 | 28 | 30 | 95.74 |
| 1200 | 1220 | – | 1405 | 1232 | 60 | 1340 | 5 | 32 | 33 | 155.87 |
Rizwan Flanges, a leading supplier in Manama, Bahrain, offers an extensive selection of DIN 2641 PN6 Lap Joint Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2641 PN6 Lap Joint Flanges are widely used in piping systems requiring frequent disassembly or realignment. Their flexibility and ease of installation make them ideal for low-pressure applications in industries such as water treatment, chemical processing, and food processing. These flanges are commonly employed in non-corrosive fluid transport systems, ensuring leak-free connections and straightforward maintenance. They are particularly useful in situations where alignment adjustments are crucial, providing cost-effective and reliable solutions for various industrial and commercial piping setups.
Yes, we offer custom sizes for DIN 2641 PN6 Lap Joint Flanges to meet specific project needs. Our team at Rizwan Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@rizwanflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2641 PN6 Lap Joint Flange Dimensions | Raised Face DIN 2641 PN6 Lap Joint Flange Manufacturer |
| Alloy Steel DIN 2641 PN6 Lapped Joint Flanges | Copper Nickel DIN 2641 PN6 Lap Joint Flanges at Best Price |
| DIN 2641 PN6 Lap Joint Flange Manufacturer | Flat Face DIN 2641 PN6 Lap Joint Flange Manufacturer |
| 18 inch DIN 2641 PN6 Carbon Steel Lap Joint Flange | DIN 2641 PN6 Lap Joint Flange Dimensions in mm |
| Stainless Steel DIN 2641 PN6 Lap Joint Flange | ASTM B564 Raised Faced DIN 2641 PN6 Lap Joint Flanges |
| DIN 2641 PN6 LJ Flange Exporter | DIN 2641 PN6 Lap Joint Flange Pressure Ratings |
| DIN 2641 PN6 LJ Flange Stockist in Bahrain | Raised Faced DIN 2641 PN6 Slip-On flanges Dealer in Bahrain |
| DIN 2641 PN6 LJ Flanges Supplier in Manama | Alloy Steel DIN 2641 PN6 Lap Joint Flanges Manufacturer in Bahrain |
| Raised Face DIN 2641 PN6 Lap Joint Plate Flanges | Titanium DIN 2641 PN6 Lapped Joint Flanges |
| DIN 2641 PN6 Lapped Joint FF Flange Supplier | Suppliers of DIN 2641 PN6 Lap Joint Flange |
| DIN 2641 PN6 Lap Joint Pipe Flanges Supplier in Sitrah | Duplex Steel DIN 2641 PN6 Lap Joint Flanges |
| 4 inch Stainless Steel DIN 2641 PN6 Lap Joint Flange | DIN 2641 PN6 Lap Joint RF Flanges Stockholder |
| 30 inch DIN 2641 PN6 Lap Joint Flange Dealer | Raised Face DIN 2641 PN6 Lap Joint Flanges Manufacturer |
| 8 Inch DIN 2641 PN6 Lapped Joint Pipe Flanges | DIN 2641 PN6 Lap Joint Flanges Stockist |
| Carbon Steel Raised Face DIN 2641 PN6 Lap Joint Flange Stockist | Duplex Steel DIN 2641 PN6 LJ Flanges Supplier in Manama |
| DIN 2641 PN6 LJ Flanges Distributor in Riffa | Flat Face DIN 2641 PN6 Lap Joint Flanges Exporter |
| DIN 2641 PN6 Lapped Joint Flanges Supplier in A’ali | MS DIN 2641 PN6 Lap Joint Flange |
| ASME SA105N Raised Faced DIN 2641 PN6 Lap Joint Flanges | 18 inch Carbon Steel DIN 2641 PN6 Lap Joint Flange |
| DIN 2641 PN6 Lap Joint Pipe Flanges Wholesaler | DIN 2641 PN6 LJ Flanges Supplier |
| Nickel Alloy DIN 2641 PN6 Lapped Joint Flange | Mild Steel DIN 2641 PN6 Lap Joint Flange |
| Carbon Steel DIN 2641 PN6 Lapped Joint Flange | DIN 2641 PN6 Lap Joint RF Flange Supplier |
| German Standard DIN 2641 PN6 Lap Joint Flanges | DIN 2641 PN6 Lap Joint Flange Supplier in Bahrain |
| DIN 2641 PN6 Large Diameter Lap Joint Flange | 30 Inch DIN 2641 PN6 Lap Joint Pipe Flange Dimensions |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
