Strategically located in the industrial heart of Manama, Bahrain, Rizwan Flanges has built a strong reputation for precision engineering and reliable supply. We take pride in being your trusted partner for critical pipeline components, including the robust DIN 2566 PN16 Threaded Flanges. Our commitment is to deliver products that meet the highest international standards, ensuring strength and durability for your most demanding projects. We understand that dependable infrastructure starts with quality components, and our threaded flanges are manufactured with this core principle in mind.
Crafted to meet the precise specifications of the DIN 2566 standard for a PN16 pressure rating, these threaded flanges are typically manufactured from high-grade carbon steel. This composition provides an excellent balance of strength and malleability. The resulting mechanical properties ensure they can withstand significant pressure and structural stress without compromising their integrity. This makes them a reliably sturdy choice, capable of maintaining a secure seal in a variety of challenging operating conditions.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | D | b | k | h1 | d3 | d4 | f | Holes | Thread | d2 | Kg | |
| 15 | 21,3 | R 1/2 | 95 | 14 | 65 | 20 | 35 | 45 | 2 | 4 | M 12 | 14 | 0,613 |
| 20 | 26,9 | R 3/4 | 105 | 16 | 75 | 24 | 45 | 58 | 2 | 4 | M 12 | 14 | 0,91 |
| 25 | 33,7 | R 1 | 115 | 16 | 85 | 24 | 52 | 68 | 2 | 4 | M 12 | 14 | 1,1 |
| 32 | 42,4 | R 1 1/4 | 140 | 16 | 100 | 26 | 60 | 78 | 2 | 4 | M 16 | 18 | 1,6 |
| 40 | 48,3 | R 1 1/2 | 150 | 16 | 110 | 26 | 70 | 88 | 3 | 4 | M 16 | 18 | 1,78 |
| 50 | 60,3 | R 2 | 165 | 18 | 125 | 28 | 85 | 102 | 3 | 4 | M 16 | 18 | 2,43 |
| 65 | 76,1 | R 2 1/2 | 185 | 18 | 145 | 32 | 105 | 122 | 3 | 4 | M 16 | 18 | 3,18 |
| 80 | 88,9 | R 3 | 200 | 20 | 160 | 34 | 118 | 138 | 3 | 8 | M 16 | 18 | 4,12 |
| 100 | 114,3 | R 4 | 220 | 20 | 180 | 38 | 140 | 158 | 3 | 8 | M 16 | 18 | 4,47 |
| 125 | 139,7 | R 5 | 250 | 22 | 210 | 40 | 168 | 188 | 3 | 8 | M 16 | 18 | 6,13 |
| 150 | 165,1 | R 6 | 285 | 22 | 240 | 44 | 195 | 212 | 3 | 8 | M 20 | 22 | 7,92 |
Rizwan Flanges, a leading supplier in Manama, Bahrain, offers an extensive selection of DIN 2566 PN16 Threaded Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2565 PN6 Threaded Flanges are commonly used in low-pressure systems where frequent disassembly or maintenance is required. They are ideal for water treatment facilities, construction projects, and light industrial applications, as they can be easily screwed into place without the need for welding. These flanges securely connect pipes and equipment, ensuring leak-free performance and straightforward installation. Their versatility and ease of use make them suitable for applications involving non-corrosive fluids, where a reliable, cost-effective, and easy-to-maintain connection is essential.
Yes, we offer custom sizes for DIN 2566 PN16 Threaded Flanges to meet specific project needs. Our team at Rizwan Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@rizwanflanges.com.
