Located in the industrial heart of Manama, Bahrain, Rizwan Flanges has built a reputation for precision and reliability in the piping industry. Our commitment to quality shines through in products like the DIN 2565 PN6 Threaded Flange, designed for seamless integration into a wide array of systems. We understand that the integrity of your projects depends on strong, dependable components, which is why we ensure our flanges are manufactured to the highest standards, providing a secure and efficient solution for connecting pipes and equipment without the need for welding.
Crafted with careful attention to material composition, these flanges are typically made from robust carbon or stainless steel, ensuring they can handle the demands of various environments. Their mechanical properties are governed by strict standards, guaranteeing excellent tensile strength and durability. This means they are built to withstand a pressure rating of PN6, providing a reliable seal and a long service life even under consistent pressure, making them a trustworthy choice for your critical piping assemblies.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | D | b | k | h1 | d3 | d4 | f | Holes | Thread | d2 | Kg | |
| 15 | 21,3 | R 1/2 | 80 | 12 | 55 | 20 | 30 | 40 | 2 | 4 | M 10 | 11 | 0,373 |
| 20 | 26,9 | R 3/4 | 90 | 14 | 65 | 24 | 40 | 50 | 2 | 4 | M 10 | 11 | 0,59 |
| 25 | 33,7 | R 1 | 100 | 14 | 75 | 24 | 50 | 60 | 2 | 4 | M 10 | 11 | 0,743 |
| 32 | 42,4 | R 1 1/4 | 120 | 14 | 90 | 26 | 60 | 70 | 2 | 4 | M 12 | 14 | 1,05 |
| 40 | 48,3 | R 1 1/2 | 130 | 14 | 100 | 26 | 70 | 80 | 3 | 4 | M 12 | 14 | 1,2 |
| 50 | 60,3 | R 2 | 140 | 14 | 110 | 28 | 80 | 90 | 3 | 4 | M 12 | 14 | 1,37 |
| 65 | 76,1 | R 2 1/2 | 160 | 14 | 130 | 32 | 100 | 110 | 3 | 4 | M 12 | 14 | 1,92 |
| 80 | 88,9 | R 3 | 190 | 16 | 150 | 34 | 110 | 128 | 3 | 4 | M 16 | 18 | 2,82 |
| 100 | 114,3 | R 4 | 210 | 16 | 170 | 38 | 130 | 148 | 3 | 4 | M 16 | 18 | 3,19 |
| 125 | 139,7 | R 5 | 240 | 18 | 200 | 40 | 160 | 178 | 3 | 8 | M 16 | 18 | 4,47 |
| 150 | 165,1 | R 6 | 265 | 18 | 225 | 44 | 185 | 202 | 3 | 8 | M 16 | 18 | 5,3 |
Rizwan Flanges, a leading supplier in Manama, Bahrain, offers an extensive selection of DIN 2565 PN6 Threaded Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2565 PN6 Threaded Flanges are commonly used in low-pressure systems where frequent disassembly or maintenance is required. They are ideal for water treatment facilities, construction projects, and light industrial applications, as they can be easily screwed into place without the need for welding. These flanges securely connect pipes and equipment, ensuring leak-free performance and straightforward installation. Their versatility and ease of use make them suitable for applications involving non-corrosive fluids, where a reliable, cost-effective, and easy-to-maintain connection is essential.
Yes, we offer custom sizes for DIN 2565 PN6 Threaded Flanges to meet specific project needs. Our team at Rizwan Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@rizwanflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2565 PN6 Threaded Flanges Supplier in Manama | Alloy Steel DIN 2565 PN6 Threaded Flanges Manufacturer in Bahrain |
| DIN 2565 PN6 Screwed Flange Stockist in Bahrain | Raised Faced DIN 2565 PN6 Slip-On flanges Dealer in Bahrain |
| ASME SA105N Raised Faced DIN 2565 PN6 Threaded Flanges | 18 inch Carbon Steel DIN 2565 PN6 Threaded Flange |
| Stainless Steel DIN 2565 PN6 Threaded Flange | ASTM B564 Raised Faced DIN 2565 PN6 Threaded Flanges |
| Carbon Steel Raised Face DIN 2565 PN6 Screwed Flange Stockist | Duplex Steel DIN 2565 PN6 Threaded Flanges Supplier in mm |
| DIN 2565 PN6 Threaded Flange Dimensions | Raised Face DIN 2565 PN6 Threaded Flange Manufacturer |
| Carbon Steel DIN 2565 PN6 Threaded Flange | DIN 2565 PN6 Threaded RF Flange Supplier |
| DIN 2565 PN6 Threaded Flanges Distributor in Sitrah | Flat Face DIN 2565 PN6 Threaded Flanges Exporter |
| DIN 2565 PN6 Threaded Flange Manufacturer | Flat Face DIN 2565 PN6 Screwed Flange Manufacturer |
| 30 inch DIN 2565 PN6 Threaded Flange Dealer | Raised Face DIN 2565 PN6 Threaded Flanges Manufacturer |
| 18 inch DIN 2565 PN6 Carbon Steel Threaded Flange | DIN 2565 PN6 Threaded Flange Dimensions in mm |
| 8 Inch DIN 2565 PN6 Threaded Pipe Flanges | DIN 2565 PN6 Threaded Flanges Stockist |
| Alloy Steel DIN 2565 PN6 Threaded Flanges | Copper Nickel DIN 2565 PN6 Threaded Flanges at Best Price |
| Nickel Alloy DIN 2565 PN6 Threaded Flange | Mild Steel DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Screwed Flanges Supplier in Riffa | MS DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Threaded Flange Exporter | DIN 2565 PN6 Threaded Flange Pressure Ratings |
| DIN 2565 PN6 Large Diameter Threaded Flange | 30 Inch DIN 2565 PN6 Threaded Pipe Flange Dimensions |
| Raised Face DIN 2565 PN6 Threaded Plate Flanges | Titanium DIN 2565 PN6 Threaded Flanges |
| 4 inch Stainless Steel DIN 2565 PN6 Threaded Flange | DIN 2565 PN6 Screwed RF Flanges Stockholder |
| DIN 2565 PN6 Threaded FF Flange Supplier | Suppliers of DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Threaded Pipe Flanges Supplier in A’ali | Duplex Steel DIN 2565 PN6 Threaded Flanges |
| German Standard DIN 2565 PN6 Threaded Flanges | DIN 2565 PN6 Threaded Flange Supplier in Bahrain |
| DIN 2565 PN6 Threaded Pipe Flanges Wholesaler | DIN 2565 PN6 Threaded Flanges Supplier |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
